Specifications
CPU Specifications
Total Cores
20
# of Performance-cores
8
# of Efficient-cores
12
# of Low Power Efficient-cores
0
Total Threads
20
Max Turbo Frequency
5.3 GHz
Intel Turbo Boost Max Technology 3.0 Frequency
5.3 GHz
Performance-core Max Turbo Frequency
5.2 GHz
Efficient-core Max Turbo Frequency
4.6 GHz
Performance-core Base Frequency
2.4 GHz
Efficient-core Base Frequency
1.8 GHz
Cache
30 MB Intel Smart Cache
Total L2 Cache
36 MB
Processor Base Power
65 W
Maximum Turbo Power
182 W
Intel Deep Learning Boost (Intel DL Boost) on CPU
Yes
AI Software Frameworks Supported by CPU
OpenVINO, WindowsML, DirectML, ONNX RT, WebNN
CPU Lithography
TSMC N3B
Memory Specifications
Max Memory Size (dependent on memory type)
256 GB
Memory Types
Up to DDR5 6400 MT/s
Max # of Memory Channels
2
ECC Memory Supported
Yes
GPU Specifications
GPU Name
Intel Graphics
Graphics Base Frequency
300 MHz
Graphics Max Dynamic Frequency
1.95 GHz
GPU Peak TOPS (Int8)
8
Graphics Output
eDP1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL
Xe-cores
4
Max Resolution (HDMI)?
4096 x 2304 @ 60Hz (HDMI 2.1 TMDS)
7680 x 4320 @ 60Hz (HDMI 2.1 FRL)
Max Resolution (DP)?
7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)?
3840 x 2400 @ 120Hz
DirectX* Support
12
OpenGL* Support
4.5
OpenCL* Support
3
H.264 Hardware Encode/Decode
Yes
H.265 (HEVC) Hardware Encode/Decode
Yes
AV1 Encode/Decode
Yes
Intel Quick Sync Video
Yes
# of Displays Supported ?
4
Intel Deep Learning Boost (Intel DL Boost) on GPU
Yes
AI Software Frameworks Supported by GPU
OpenVINO, WindowsML, DirectML, ONNX RT, WebGPU
NPU Specifications
NPU Name?
Intel AI Boost
NPU Peak TOPS (Int8)
13
Sparsity Support
Yes
Windows Studio Effects Support
Yes
AI Software Frameworks Supported by NPU
OpenVINO, WindowsML, DirectML, ONNX RT, WebNN
Expansion Options
Direct Media Interface (DMI) Revision
4
Max # of DMI Lanes
8
Intel Thunderbolt 4
Yes
Scalability
1S Only
PCI Express Revision
5.0 and 4.0
PCI Express Configurations ?
Up to 1x16+2x4, 2x8+2x4, 1x8+4x4
Max # of PCI Express Lanes
24
Package Specifications
Sockets Supported
FCLGA1851
Thermal Solution Specification
PCG 2022C
Max Operating Temperature
105 C
Package Size
45 mm x 37.5 mm
INTEL · Processors
Intel Core (BX80768265) Ultra 7 Processor 265 Processor 20 Core
- Manufacturer part no.
- BX80768265
- Brand
- INTEL
£349.32
inc. VAT · £291.10 ex. VAT · UK VAT at 20%
Specification
| Socket | 1851 |
|---|---|
| On-Chip Graphics | No |
| Speed | 2.4GHz |
| Core Quantity | 20 |
| Prefix | Ultra 7 |
Warranty
3 Years Manufacturers Warranty, Tel Warranty claims are handled by us on 0118 359 2220.
Compatibility · socket LGA 1851
Boards that take this processor
-
Gigabyte Z890 UD WIFI6E Ultra Durable Intel 1851 Socket Mothe...
£184.58
-
Gigabyte Z890 GAMING X WIFI7 Intel 1851 Socket Motherboard
£222.80
-
Gigabyte Z890 EAGLE WIFI7 PLUS Intel 1851 Socket Motherboard
£231.73
-
Gigabyte Z890 D PLUS Intel 1851 Socket Motherboard
£185.06
-
Gigabyte Z890 AORUS PRO ICE Intel 1851 Socket Motherboard
£268.79
-
Gigabyte Z890 AORUS MASTER Intel 1851 Socket Motherboard
£335.99
Intel Core (BX80768265) Ultra 7 Processor 265 Processor 20 Core, 20 Threads, 2.4GHz up to 5.3GHz Turbo, LGA 1851 Socket, 66MB Cache, 65W, Maximum Turbo Power182W
